KiCAD schematics for Dasduino CONNECTPLUS and HX711 load-cell amplifier

TECHNICAL SUPPORT NULA Development Boards
1

Customer:

I’m working on a thesis project with the Dasduino CONNECTPLUS (ESP32) and the Load-cell amplifier HX711 with easyC connector. Could you provide KiCAD schematics for these products?

Original message (Croatian)

Ovim putem se javljam da provjerim i ujedno zamolim da mi pošaljete, ako imate, KiCAD sheme od sljedećih proizvoda:

Dasduino CONNECTPLUS (ESP32)

Load-cell pojačalo HX711 s easyC

Radim diplomski rad s ovim komponentama na temu "

Prikupljanje i obrada podataka korištenjem IoT uređaja s primjenom u rehabilitaciji", na FESB-u.

Originally submitted via email support on 1 April 2025. Migrated to the forum for community visibility.

2

Soldered Support:

The KiCAD projects are available in these repositories:

The CAD folders contain the KiCAD projects, and the OUTPUTS folders contain the schematics.

Original message (Croatian)

naravno, evo repozitorija s ovim podatcima:
GitHub - SolderedElectronics/Dasduino-CONNECTPLUS-hardware-design: Hardware design, BOM, gerbers and 3D files for Dasduino-CONNECTPLUS designed by Soldered Electronics. · GitHub
GitHub - SolderedElectronics/Load-cell-amplifier-HX711-board-qwiic-hardware-design: Hardware design, BOM, gerbers and 3D files for Load-cell-amplifier-HX711-board-qwiic designed by Soldered Electronics. · GitHub
GitHub - SolderedElectronics/Load-cell-ampfilier-HX711-board-hardware-design: Hardware design, BOM, gerbers and 3D files for Load-cell-ampfilier-HX711-board designed by Soldered Electronics. · GitHub

U CAD folderima su KiCad projekti, u OUTPUTS su sheme, nadam se da će biti korisno za rad.
