Dasduino COREPLUS pins D83, D84, D85 support in Arduino IDE

TECHNICAL SUPPORT NULA Development Boards
1

Customer:

I’m using pins D83, D84, D85 in my project, but since they don’t exist in Arduino MEGA 2560 (they’re not exposed in the pinout), I’m having trouble using the Dasduino COREPLUS board in Arduino IDE. Is there a board support package for Dasduino COREPLUS, or another way to use pins 83, 84, 85?

Original message (Croatian)

Pozdrav, u projektu koristim pinove D83, D84, D85, ali budući da njih nema u Arduino MEGA 2560 (tj. nisu izvedeni u pinout) imam problema s korištenjem pločice Dasduino COREPLUS u Arduino IDE-u. Zanima me postoji li neki board support package za Dasduiino COREPLUS, ili neki drugi način za koristiti pinove 83, 84, 85.

Hvala

Originally submitted via email support on 19 May 2025. Migrated to the forum for community visibility.

2

Soldered Support:

Use the Dasduino board definitions for Arduino IDE available here:

With that board definition, you can use the pins like this:

pinMode(84, OUTPUT);

This should work. If it doesn’t, let me know and I’ll investigate further.

Original message (Croatian)

evo linka do tutoriala kako dodati naše Dasduino board definitione u Arudino:
GitHub - SolderedElectronics/Dasduino-Board-Definitions-for-Arduino-IDE · GitHub

Probaj s tim board definitionom koristiti pinove kao:
pinMode(84, OUTPUT);
Što bi trebalo biti OK, ako nije, javi pa osobno pogledam.
